CIFICATIONS
4 Pairs Unshielded Twisted Pair (UTP) Cable
Conductor Metal: Bare Copper
Color Code: BLUE
Conductor: 24 AWG
Insulation Material: HD-PE
Jacket Material: PVC UL94V-0
Heat-resistant: 60oC minimum (Temperature limited)

MODULAR CONNECTOR/PLUG
RJ-45 8P for Transparence color.
Gold plated: 50U
Contact blade: Phosphor Bronze
Temperature range: -10 ~ 80C
Dielectric withstanding voltage: 500V AC
Insulation resistance: 35M Ohm (max.)
Durability: 750 matching cycles
Cable-to-plug tensile strength: 20lbs (89N) (min.)
UL applications: 250V AC, 2A (max.)
Polycarbonate (PC) UL94-V-0

APPLICATION
D-Link solid cables are the best twisted-pair cables in the market for transmitting data
over local area Networks (LANs). These cables exceed performance requirements
specified by the TIA/EIA-568B.2 / TIA/EIA-568C.2 and IEC 60603-7-4 standards.
10BASE-T, 100BASE-TX Fast Ethernet,
1000BASE-T (IEEE802.3)
100VG-AnyLAN (IEEE802.12)
550 MHz Broadband Video
Voice, T1, ISDN
155/ 622 Mbps ATM
Power over Ethernet (POE)
